Used 2007 OKUMA MCV-AII | UMC (3-4 AXIS)

Capacity
Effective Width Between Columns mm(in) 2,050 (80.71)
Table to Spindle Nose mm(in) 0-1510 (59.45)
X-Axis (table front/back) mm(in) 3,000 (118.11)
Y-Axis (spindlehead horizontal) mm(in) 2,000 (78.74)
Z-Axis (quill Vertical) mm(in) 450 (17.72)

Table
Size (width x length) mm(in) 1,500 x 3,100 (59.06 x 122.05)
Working Surface (width x length) mm(in) 1,500x 2,800 (59.06 x 110.24)
T-Slots (width x no.) mm(in) 20 x 11 (0.79) {center: 140 (5.51)}
Height From Machine Bottom mm(in) 750 (29.53)
Cutting Feedrate mm/min(ipm) 1-10,000 (0.01-394)
Rapid Traverse mm/min(ipm) 20,000 (787)
Max Load Capacity kg(lb) 10,000 (22,000)

Spindle
Bearing Diameter mm(in) 85 (3.35)
Taper Bore 7/24 taper no. 50
Tool Clamping Pull Stud (MAS 2)
Speed Range min-1(rpm) 30-6,000

Quill
Bearing Diameter mm(in) 210 (8.72)
Cutting Feedrate mm/min(ipm) 1-10,000 (0.01-394)
Rapid Traverse mm/min(ipm) 10,000 (394)

Spindlehead
Cutting Feedrate mm/min(ipm) 1-10,000 (0.01-394)
Rapid Traverse mm/min(ipm) 20,000 (787)

Crossrail
Travel mm(in) 1,150 (45.28)
Traverse Rate mm/min(ipm) 50/60 Hz 420/500

ATC
Tool Shank Type MAS403 BT50
Tool Magazine Capacity 72
Max Tool Diameter mm(in) w/adjacent tools 128 (5.04) w/o adjacent tool 230 (9.06)
Max Tool Lenght/Weight mm/kg(in/lb) 40/20 (15.75/44)
Max Tool Weight and Moment kgxmm(lbxin) 20 x 150 (44 x 5.91)
Tool Selection Fixed Address Random Selection

Motors
Spindle Drive (30 min/cont) 22/15 (30/20)
Spindlehead Brushless Servo 4.2 (5.6)
Table Brushless Servo3.5 (4.8)
Quill Brushless Servo 4.2 (5.6)
Crossrail Vertical Drive 3.7 (4.9) (AC) auto-positioning crossrail specs: 3.6

Size
Height mm(in) 4,585 (181)
Floor Space (machine only) mm(in) 5,140 x 8,100 (202 x 319)
Net Weight (machine only) kg(lb) 31,500 (69,300)
