Used 2004 HAAS VF-5 | VMC (5 AXIS)
Have one to sell?
ConditionUsed
1 available
X Axis Travel: 50"
Y Axis Travel: 26"
Z Axis Travel: 25"
Rapid Rate X Axis: 710 IPM
Rapid Rate Y Axis: 710 IPM
Rapid Rate Z Axis: 710 IPM
Max Table Load: 4,000 LBS
Spindle Motor: 30 HP
Spindle Speed: 10,000 RPM
Spindle Taper: 40 CT
Tool Changer: 30 ATC
Max Cutting 500 ipm
Max Thrust X 2550 lbf
Max Thrust Y 4100 lbf
Max Thrust Z 4100 lbf
Max Tool Diameter 3.5"
Max Tool Weight 12 lb
Tool-to-Tool (avg) 4.2 s
Chip-to-Chip (avg) 4.5 s
Table Size: 54" x 24"
Dimensions: 168" x 101" x 109"
Weight: 12,700 LBS
Thru Spindle Coolant
30 HP 2 Speed Gearbox
*Specifications Subject to Buyer Verification.
