Used 2015 HAAS UMC-750 | VMC (5 AXIS)

Travels
X Axis 30" 762 mm
Y Axis 20" 508 mm
Z Axis 20" 508 mm
C-Axis Rotation 360° Rotation
B-Axis Tilt -35° to +110°
Spindle Nose to Table (~ min.) 4" 102 mm
Spindle Nose to Table (~ max.) 24" 610 mm
Table
Width 19.7" 500 mm
Length 24.8" 630 mm
T-Slot Width 5/8" 16 mm
T-Slot Center Distance 2.48" 63 mm
Number of Standard T-Slots 7
Max. Weight on Table (evenly distributed) 660 lb 300 kg
General Requirements
Air Required 4 scfm, 100 psi 113 L/min, 6.9 bar
Coolant Capacity 75 gal 284 L
Power Requirement, Low Voltage 195-260 VAC / 100A
Power Requirement, High Voltage 354-488 VAC / 50A
Machine Weight 18,000 lb 8165 kg
