Used 2018 WEST MICHIGAN SPLINE 24 | Spline Rollers
Have one to sell?
ConditionUsed
1 available
Rack Size: 24”
OD: 1.5”
Max Rack Box Depth: 5.0”
Opening: 5.5”
Under Arm Support with Tailstock
One-Piece Welded Construction
No Shimming Required for Straightness
Runs Various Lengths w/ No Induced Taper
Cold Form Splines and Threads w/o Tie Bars
Coolant System
Hydraulic Tank Reservoir: 50 Gallons
Overall Machine Dimensions (approx.): 120” x 72” x 161” Tall
System Weights (approximate):
Machine Weight: 25,000 lbs.
Hydraulic Tank & Stand Weight: 5,700 lbs.
