Used 2016 DMG MORI NTX2000/1500SZ | 5-Axis or More CNC Lathes

Chuck size Spindle 1 / Spindle 2 8-inch or 10-inch / 8-inch or 10-inch
Max. distance between centers mm (in.) 1,822 (71.7)
Max. turning length mm (in.) 1,538 (60.5)
Max. turning diameter (Tool spindle) mm (in.) 670 (26.3)
Max. turning diameter, Turret 2 mm (in.) 325 (12.7)
Swing over cross slide mm (in.) 700 (27.5)
Max. spindle speed Spindle 1 / Spindle 2 5,000 min-1 / 5,000 min-1
Bar work capacity Spindle 1 mm (in.) 65 (2.5)
Bar work capacity Spindle 2 mm (in.) 65 (2.5)
B-axis (Tool spindle) 240° (±120°)
Min. indexing increment 0.0001º
Max. tool spindle speed min-1 12,000
Taper hole of tool spindle HSK-A63
X1-axis (Tool spindle) mm (in.) 675 (26.5) -125 - +550 (-4.9 - +21.6)
Y1-axis travel (Tool spindle) mm (in.) 300 (11.8) <±150 (±5.9)
Z1-axis (Tool spindle) ＋ for ATC mm (in.) 1,562 (61.4) ＋ 164 (6.4) For ATC
Max. tool diameter (With adjacent tools) mm (in.) 70 (2.7)
Max. tool diameter (Without adjacent tools) mm (in.) 130 (5.1)
Max. tool length mm (in.) 400 (15.7)
Max. tool mass kg (lb.) 8 (17.6)
