Used 2017 TSUGAMI B038T | Swiss Type Automatic Screw Machines
Have one to sell?
ConditionUsed
1 available
Maximum Bar Stock 38 mm / 1.5″
# Axes 9
Sliding Headstock / Guide Bushing YES
CONVERTIBLE: Run w/o Guide Bushing (chucker) NO
Max Headstock Stroke w/ Guide Bushing 250 mm / 9.84”
# Tool Positions (std / max) 45 max
# Live Tool Positions (std / max) 8 Rotary Tools (Turret) 2 (Gang Slide)
Control FANUC 31i-B
Main Spindle Speed 200 – 5,000 rpm
Sub Spindle Speed 200 – 7,000 rpm
Live Tool Speed 200 – 8,000 rpm
Main Spindle Motor 7.5 / 11 kW
Weight 6,200 kg / 13,669 lbs.
Footprint: W x D x H 3,247 × 1,875× 1,840 mm
134.9″ x 73.8″ x 72.4″
* Specifications Subject to Buyer Verification.
